Olimp M46 cabin
Very fast, comfortable and agile vessel with excellent handling, designed for immediate deployment and efficient operations.
Next-Generation Military Vessel
Modern high-speed patrol/military boat designed for demanding maritime security and defense operations.
Olimp Defense Group
M46 CABIN
OLIMP M46 is a Next-Generation Military Vessel designed for demanding maritime security and defense operations. Developed as a versatile multi-role platform, the M46 combines robust construction, high maneuverability, and reliable performance in coastal and near-shore environments.
Hull
The hull features a modern design and advanced construction technology. It is a Deep-V stepped hull with two levels (steps), manufactured from GRP with vinylester resin and reinforced with a minimum of 33.33% Kevlar. The hull is produced using a 3D vacuum infusion process.
Deck
The deck is of robust construction with a non-slip surface. It is also self-draining, both while underway and when stationary. The structure is reinforced with aluminium and aramid to provide additional strength, durability, and resistance to operational loads.
Eye bolts are installed on the deck in appropriately balanced and reinforced positions for attaching lifting straps when hauling or hoisting the boat by crane at full load. Their placement ensures that they do not hinder the movement of personnel on board.
Seats
The vessel is equipped with two (2) seats positioned side by side for the pilot and co-pilot, and two (2) additional seats located behind them. These seats are fitted with specialized shock-absorbing mounts for vibration damping to ensure crew safety and comfort during operations in adverse sea conditions.
The M46 can also be configured with up to ten (10) Ullman shock-mitigating seats for soldiers or additional personnel.
In total, the vessel can accommodate up to twenty-two (22) seats depending on the selected configuration.
Weaponry mounts
The vessel is equipped with a prepared base platform for weapon systems, either manually operated or remotely controlled (RWS), supporting calibers of up to 20 mm.
Anchor and Anchor width
The anchor is of the BRUCE type, with size and weight suitable for the proposed vessel, and is manufactured from stainless steel (INOX).
The anchor is retrieved using an electric windlass, 12 V or 24 V DC depending on the vessel’s power supply, with a minimum power of 800 W. The windlass can also be operated manually.
At the bow of the vessel, there is a locker or hatch for storing the anchor and chain. The anchor locker is equipped with a drainage system to remove seawater.
Cleats
Double eye cleats are installed on the deck or in other suitable locations. The cleats are handmade from stainless steel 316L and are positioned at the bow and stern of the vessel on both the port and starboard sides.
Colors
The hull, deck, and command console are in NATO digital camouflage colors.
LOA
14.25m
Top speed
+60 knots
Water Tank
100 L
Fuel tank
1500 L
Range
240 NM
(at 100% power)
Passengers
14
Technical specifications
Total Lenght
14.25 meters
Total Width
4.20 meters
Internal Length
13.50 meters
Internal width
2.55 meters
Air tube diameter
0.80 meters
Draft
0.49 meters
[1] The total length is defined as the length from the outer edge of the bow air tube until the rear platform.
[2] The overall width is defined as the width measured from the outer edge of the air tubes.
[3] The internal length is defined as the length from the edge of the inner part of the air tube until the first touch with rear platform.
[4] The internal width is defined as the width measured from the inner side of the air tube of the boat.
[5] Tubus are made from Hypalon (Orca) 1.54 kg /m– military grey (1690 dtex)
